Key Features
- Dual-acting single cylinder
- Quick, easy attachment
- See brochure for loader series compatibility
Features
Hydraulics create ease for the operator
The AM11 Series Manure Fork Grapples have a dual-acting, single-cylinder operation, which includes hoses and tips.
Fits 300-500 Series Loaders
Fits 600 and 700 Series Loaders
Global (fits all series loaders)
The Frontier™ quick-change and global attachment systems are designed for quickly removing and reattaching the AM11 Series without tools and with minimal physical effort.
This means the same tractor and loader can be used for many different tasks.
Dimensions
| Width | 213.4 cm 84 in. |
| Height | 61 cm 24 in. |
| Depth | 66 cm 26 in. |
| Cutting width | 213.4 cm 84 in. |
Attachment carrier
| Current series style | 600, 700 |
Weight
| Operating | 266.3 kg 587 lb |
| Shipping | 288.9 kg 637 lb |
Spears
| Location | Bottom |
| Size diameter | 3.8 cm 1.5 in. |
| Spacing | 21.6 cm 8.5 in. |
Hydraulic cylinders
| Type | One double-acting |
Grapple
| Grapple opening | 94 cm 37 in. |
| Open | 8,696.3 N 1,955 lb-ft |
| Closed | 6,200.8 N 1,394 lb-ft |
Set-up time
| Labor hours | 0.5 |
Warranty
| Time period | 1 year |
